Items

 Parameter

 Overall weight

59t

Overall

dimension

 Length

10600mm

 Width

 Shovel plate

3600/3200/3000mm

 Main body

2600mm

Height

 Cuting head is laid hoizontially on the highest point

2300mm

 Main body

1800mm

Undercut depth (telescopic/contracted)

440/215mm

 Ground clearance of machine

200mm

of

positioning cutting

Height (telescopic/contracted)

5200/4600mm

Width (telescopic/contracted)

6500/5800mm

Area (telescopic/contracted)

33.8/22.68m2

Gantry height (mm)

400mm

 Grade ability

±  18°

 Travelling speed

7.7m/min

 Grounding pressure

0.14MPa

 Gross power

325kW

 Power of Cutting motor

200/110kW

 Power of electric pump motor

110kW

 Input voltage

AC1140V

 Input frequency

50Hz

 Rotation speed of cutting head

46/23r/min

 Loading capacity

 Star wheel type/4.2 m³/min

 Crawler width

600mm

 Out.width of crawlers

2600mm

 Tensioning style

 Cylinder tensioning and snap-gauge locking

 Water pressure of spraying

 Water pressure of outside spraying ≥4MPa

 Water pressure of inside spraying ≥2MPa

 Max. non-removable parts size

3.13×1.39×1.5m

 Max. non-removable parts mass

6100kg

 Economic cutting rock hardness

65MPa
